Aluminium Electrical Detonators with 500 ms Delay Interval
It is a detonator having electrically ignitable fusehead by the action of dynamo type or condenser type exploder with delay time. They are used to blast dynamite and similar explosives at desired intervals and sequence to obtain a good and uniform fragmentation, the desired particle size, to decrease vibration and to increase the yield of the blasting in the great blasting operations. It can be manufactured at the desired cable length.
| Technicial Specifications | |
|---|---|
| Shell: | Aluminium |
| Delay Number: | 1-10 |
| Mark on the Butttom of the cap: | K1 - K10 |
| Delay Time: | 500-5000 ms |
| Cable: : | Electrolytic copper wire coated with PVC |
| Cable Length: | 1.5 and 2.5 m |
| Detonation Velocity: | Approximately 7500 m/s |
| Blasting Power: | It makes a min 5 mm hole in diameter on 5 mm thick lead plate. |
| Fusehead Resistance: | Class 1: 1.2-1.8 Ω / Class 2: 0.4-0.8 Ω |
| Firing Impulse: | Class 1: 3 mWs/Ω / Class 2: 16 mWs/Ω |
| No-firing Impulse: | Class 1: 0.8 mWs/Ω / Class 2: 8 mWs/Ω |
| Safety Current: | Class 1: 0.18 A DC, 300 s / Class 2: 0.45 A DC, 300 s |
| Recommended Firing Current: | Class 1: 1.0 A / Class 2: 1.5 A |
| Grizu Safe: | Unsafe |
| Strength: | No.8 |
